Hello, a beginners question …
I’m using a Logic Pro 8 and I’m trying to analyze SPI. I also watched the tutorial at youtube.
I connected CLK, CS, MISO, MOSI and did a record. I can see my data in the capture. Then I clicked on add analyzer, select the SPI and configured my channels. But I don’t get the decoded data. What I’m doing wrong?
@kufer Glad to hear you were able to get to the bottom of that!
As a side note, you can have the analyzer ignore the CS signal as well, so that all data gets decoded regardless of the CS state. More information can be found below, under " Using the SPI Analyzer Without an Enable (Chip Select) Signal."
